General

• • Color

    Black and Gray

  • Color

    Silver

• • Capacity

    2048Wh

  • Capacity

    2048Wh

• • Net weight

    Approx. 20.3 kg

  • Net weight

    Approx. 22.1 kg

• • Dimensions

    494 × 239 × 305 mm

  • Dimensions

    494 × 242 × 305 mm

Total Output Ports

• • Total Output Ports

    9

  • Total Output Ports

    10

Total Output Power

• • Total Output Power

    2674W Max

  • Total Output Power

    3581W Max

AC Output

• • Number of AC Outlets

    4

  • Number of AC Outlets

    4

• • Output Priority

    NO

  • Output Priority

    YES

• • Max AC Output

    2400W

  • Max AC Output

    3000W

• • Output Voltage

    230V~50Hz, 2400W Total 10A Max per port (×4)

  • Output Voltage

    230V~50Hz, 3000W Total 13A Max per port (×4)

• • Surge Output

    4800W

  • Surge Output

    6000W

• • Max Output by X-Boost

    3200W

  • Max Output by X-Boost

    3900W

• • X-Fusion

    NO

  • X-Fusion

    YES

DC Output

• • Number of DC Outlets

    5

  • Number of DC Outlets

    6

• • USB-A

    1 × 18W Max

  • USB-A

    1 × 18W Max

• • USB-C

    1 × 100W Max 2 × 30W Max (Total 30W)

  • USB-C

    1 × 140W Max（HID） 2 × 45W Max（Total 45W）

• • 12V DC Output

    126W Max Car Power Output × 1:12.6V⎓10A

  • 12V DC Output

    378W Max Car Power Output × 1:12.6V⎓10A Anderson Output × 1:12.6V⎓30A

Input

• • Utility Power Charging

    2300W （Depending on Input Voltage）

  • Utility Power Charging

    2300W （Depending on Input Voltage）

• • Input Voltage

    220-240V~10A 50/60Hz

  • Input Voltage

    220-240V~10A 50/60Hz

• • 0-80% Charge time

    51 min 0.85 hour

  • 0-80% Charge time

    47 min 0.8 hour

• • 0-100% Charge time

    68 min 1.1 hour

  • 0-100% Charge time

    68 min 1.1 hour

• • Solar Charging

    500W

  • Solar Charging

    1000W (2 × 500W)

• • Generator Charging

    2400W Max

  • Generator Charging

    2400W Max

• • Alternator Charging

    500W Max Through XT60 Port

  • Alternator Charging

    1000W Max Through 4+8 Port

• • Car Charging

    12V/24V⎓8A

  • Car Charging

    12V/24V⎓8A

Battery

• • Battery Chemistry

    LFP

  • Battery Chemistry

    LFP

• • Number of Extra Battery Ports

    NO

  • Number of Extra Battery Ports

    1 （expandable to 2）

• • Type of Extra Battery Ports

    NO

  • Type of Extra Battery Ports

    4+8

• • Compatible Extra Battery

    NO

  • Compatible Extra Battery

    D2M/D3MP/D3/DP3 EB

• • Max Capacity with Extra Battery

    NO

  • Max Capacity with Extra Battery

    Up to 10kWh with 2 × DELTA Pro 3 Extra Battery

• • CTC Technology

    CTC

  • CTC Technology

    CTC

UPS

• • UPS

    10ms

  • UPS

    10ms + HID

Connection

• • Screen

    YES

  • Screen

    YES

• • Wi-Fi

    YES

  • Wi-Fi

    YES

• • Bluetooth

    YES

  • Bluetooth

    YES

• • App

    YES

  • App

    YES

Experience

• • Years of Warranty

    3+2 years

  • Years of Warranty

    3+2 years

• • Noise

    600W ≤ 25dB

  • Noise

    600W ≤ 25dB

• • Operating Altitude

    ≤3000m

  • Operating Altitude

    ≤3000m

• • Discharge Temperature

    -10-45℃

  • Discharge Temperature

    -10-45℃

• • Charge Temperature

    0-45℃

  • Charge Temperature

    0-45℃

• • Storage Temperature

    -10-45℃

  • Storage Temperature

    -10-45℃

Battery Protection

• • Battery Protection

    Over Voltage Protection, Overload Protection, Over Temperature Protection, Short Circuit Protection, Low Temperature Protection, Low Voltage Protection, Overcurrent Protection

  • Battery Protection

    Over Voltage Protection, Overload Protection, Over Temperature Protection, Short Circuit Protection, Low Temperature Protection, Low Voltage Protection, Overcurrent Protection

What’s in the Box

• • What’s in the Box

    1. EcoFlow DELTA 3 Max Portable Power Station × 1 2. AC Charging Cable × 1 3. Manuals & Warranty Card × 1

  • What’s in the Box

    1. EcoFlow DELTA 3 Max Plus Portable Power Station × 1 2. AC Charging Cable × 1 3. Manuals & Warranty Card × 1
